M36-70Wp to 100Wp |
GYP-70M |
GYP-75M |
GYP-80M |
GYP-85M |
GYP-90M |
GYP-95M |
GYP-100M |
|
Electrical Characteristics |
|||||||
|
Max Power at STC*(Wp) |
70 |
75 |
80 |
85 |
90 |
95 |
100 |
|
Max Power Voltage Vmp (V) |
16.22 |
17.80 |
18.20 |
18.50 |
18.50 |
19.00 |
19.10 |
|
Max Power Current Imp (A) |
4.31 |
4.22 |
4.40 |
4.59 |
4.86 |
5.00 |
5.26 |
|
Open Circuit Voltage Voc (V) |
21.6 |
21.6 |
22.1 |
22.2 |
22.4 |
22.4 |
22.5 |
|
Short Circuit Current Isc (A) |
4.75 |
4.72 |
4.89 |
5.14 |
5.30 |
5.50 |
5.70 |
|
Cell Efficiency (%) |
13.50 |
14.00 |
14.95 |
15.90 |
16.80 |
17.40 |
18.10 |
|
Module Efficiency (%) |
10.60 |
11.60 |
12.37 |
13.15 |
13.92 |
14.33 |
14.88 |
|
Tolerance (%) |
±3 |
||||||
|
Solar Cell |
125×125 mm Mono|36 (4×9) |
||||||
|
Max system Voltage (V) |
1000 |
||||||
|
Operating Module Temperature (℃) |
-40~+85 |
||||||
|
Nominal Operating Cell Temperature(℃) |
47±2 |
||||||
|
Temperature Coefficient of Pmax (%/℃) |
-0.44 |
||||||
|
Temperature Coefficient of Voc (%/℃) |
-0.33 |
||||||
|
Temperature Coefficient of Isc (%/℃) |
0.05 |
||||||
|
Mechanical Characteristics |
|||||||
|
Dimension (mm) |
1197×554×30 |
||||||
|
Weight (Kg) |
8.0 |
||||||
|
Calbe Type,Diameter and Length |
4 mm², TUV certified, 900 mm |
||||||
|
Type of Connector |
Compatible Type IV and Type Ⅲ |
||||||
|
Junction Box |
IP65 |
||||||
|
Glass,Type and Thickness |
Ultra-white, Low Iron, Tempered Glass 3.2 mm |
||||||
|
Bypass-Diods |
2 |
||||||
|
Mechanical Load |
5400 Pa |
||||||
|
Packing Configuration |
|||||||
|
Pcs/Carton |
2 |
||||||
|
Pcs/Pallet |
70 |
||||||
|
Pcs/40ft(H) |
1960 |
||||||
特點：
1.優(yōu)質原材料
2.獨特外框設計
3.平均正公差
4.5～10年產品質保
5.25年產品性能保證
6.5400Pa機械載荷
7.世界級保險
8.全系列認證功率70瓦-280瓦，可定制功率0.1瓦-500瓦
PS：我司另有其他光伏產品（硅棒、硅片）和各類LED燈，歡迎來電來函來訪。
